Great Magtech (Xiamen) Electric Co., Ltd is one of the most reliable manufacturers and suppliers of automatic magnetic separator for electromagnetic dry powder in China. We warmly welcome you to wholesale high quality automatic magnetic separator for electromagnetic dry powder from our factory. Good service and reasonable price are available.
Product Description
1.Introduction of dry magnetic separator
It can be used to remove the weak magnetic oxides, chip-like skin contaminants such as rust from powder-like material. It has been widely used in ceramics, glass, refractory material, and other non-metallic minerals, medicine, chemical industry, purification of food materials and other industries.
2.Advantage of dry magnetic separator
1.Simple installation, convenient cleaning.
2.Its magnetism is designed uniquely.The magnetic source is permanent magnetic NdFeB materials, which is the king of magnetism.With the high magnetic field on each nodes, it has ha high gradient magnetic field and good effect of iron eliminating.
3.Little consumption.Low energy consumption and easy for operation and maintenance
4.With small size and easy disassemble.
3.Technical parameter of the machine
| Model | 3A160 | 3A220 | 7A300 |
11A220 |
11A430 | 15A220 | 20A600 |
| Magnetic field strength(t) | 2 | 2 | 3 | 3 | 3 | 5 | 3 |
| Input voltage(VAC) | 380 | 220 | 380 | 380 | 380 | 380 | 380 |
| Maximun output current(A) | 15 | 7 | 20 | 20 | 20 | 30 | 40 |
| Maximum coil power(KW) | 3 | 3 | 7 | 11 | 11 | 15 | 20 |
| Insulation category | E | E | E | E | E | E | E |
| Cooling method | water and oil cooling | water and oil cooling | water and oil cooling | water and oil cooling | water and oil cooling | water and oil cooling | water and oil cooling |
| Magnetic lumen diameter(mm) | 160 | 220 | 300 | 220 | 430 | 220 | 600 |
| Yield(m3/h) | 0.5-1.5 | 1-3 | 1.5-4 | 0.5-3 | 1.5-6 | 1-3 | 3-8 |
| Dimension(mm) |
700*700 *1450 |
860*860 *1540 |
1320*1320 *2500 |
1300*110 *1800 |
1500*1500 *2500 |
1350*1100 *1850 |
1500*1500 *2000 |
| Main machine weight(kg) | 450 | 490 | 1020 | 1130 | 1210 | 1500 | 2000 |
| Usage | 60-300 mesh feedstock of iron elimination | ||||||
