Great Magtech (Xiamen) Electric Co., Ltd is one of the most reliable manufacturers and suppliers of magnetic filter liquid trap magnet in China. We warmly welcome you to wholesale high quality magnetic filter liquid trap magnet from our factory. Good service and reasonable price are available.
Description of the Magnetic liquid trap:
Magnetic liquid traps with clamp connection or named magnetic liquid filters are designed for liquid or semi-liquid flow systems to remove ferrous contamination from liquid with various viscosity levels. With the magnetic liquid traps it can keep the liquid's purity by removing small contaminants and provide magnetic protection for liquid lines and processing equipment. It is composed of a number of the strong magnetic rod,which has been designed according to the special magnetic circuit.It is installed in the pipe and can efficiently filter the magnetic metal impurities during the liquid delivery.
Installation and use of Magnetic Water Filtration Magnetic Trap
The liquid magnetic filter interface flange and the slurry output line connected to the slurry from the filter evenly flow, after a period of time to determine the cleaning cycle after the trial.
Clean the cover before the first screw on the clamping screw, remove the casing cover parts, and then out of the magnet, adsorption on the casing of iron impurities can automatically fall off. After cleaning, install the casing into the cylinder, tighten the clamping screw, and then insert the magnet bar cover into the casing, you can continue to use.
Precautions of Magnetic Water Filtration Magnetic Trap
1. When cleaning, the extracted rod cover cannot be placed on a metal object to prevent damage to the magnetic bar.
2. Take out the magnetic bar must be placed in a clean place, the magnetic tube cannot have water.
Operation of Liquid Line Magnetic Ferrous Tube Trap Filter Separator:
As liquids or slurries are pumped through the Liquid Trap separators, ferrous contaminants adhere to the magnetic tubes or magnetic bar. The design and construction allow the tramp iron to go around the downstream side of the tubes where it is safely out of product flow and wash off are prevented. The cleaning job is achieved by removing the top plate and removing the magnetic assembly from the housing. The housing is designed not only to protect the magnet, but also to act as a sump, to reach the easy-clean and fast-clean goal.
Magnetic Filter Optional features:
1. The shell material: SS304, SS316, SS316L;
2. The magnetic strength grade: 8000Gs, 10000Gs, 12000Gs;
3. Working temperature grade: 80, 100, 120, 150, 180, 200degree Celsius;
4. Various designs available: Easy clean type, pipe in line type;
5. Compress resistance: 6 kilograms (0.6Mpa) with quick release clamp while 10 kilograms (1.0Mpa) with flange.
6. Also takes customers' designs.
